The ChipSourceTek-CST6116A is a single-channel brushed DC motor drive chip designed for a variety of small DC drive applications. Its excellent performance and diverse functions make it widely used in toy cars, electric toothbrushes and various small household appliances.

I. Main features and functions

1. Low on-resistance

ChipSourceTek-CST6116A has an extremely low on-resistance, the sum of the on-resistance of the high side (HS) and the low side (LS) is 400mΩ. This means that the energy loss of the chip is very small when the current is passed through, thus improving the overall efficiency. The maximum continuous output current is up to 1.5A and the peak current is up to 2.1A, ensuring stable operation even under large loads.

2. Full bridge drive architecture

The chip has built-in power MOS full bridge drive, which can realize many functions such as forward, backward, stop and brake. The design of full bridge drive not only simplifies the peripheral circuit, reduces the need for large filter capacitance, but also improves the reliability of the system. This structure allows the user to easily control the direction of the motor and respond quickly to the brake command。

3. Overtemperature protection function

In order to ensure the safety of the chip operation, the CST6116A has a built-in overheating protection function with hysteresis effect. When the chip temperature exceeds the safe range, it will automatically enter the protection mode to prevent damage to the device. This feature is especially important for applications that run for a long time or have high ambient temperatures.

4. Low power design

The chip adopts advanced design technology, and the typical standby current value is only 0.1uA. With such low static power consumption, it consumes almost no power in standby mode, which is a significant advantage for battery-powered portable devices.

5. Encapsulation form

The ChipSourceTek-CST6116A comes in a SOT23-6 package that is small and easy to weld, making it ideal for mass production and automated assembly. At the same time, its compact design is also easy to integrate into various miniaturized electronic products.

II. Application field

Due to its excellent performance and flexible configuration, the CST6116A is widely used in the following areas:

1. Dc brush motor drive

Whether home appliances or industrial equipment, the CST6116A provides reliable motor drive solutions. Its high efficiency and low power consumption make it the first choice of many manufacturers.

2. Toy car motor drive

In toy cars, the chip can achieve precise speed control and direction changes, bringing a more realistic driving experience to children. Its built-in protection also ensures the safety and durability of the toy.

3. Toy aircraft tail motor drive

For toy aircraft, the CST6116A provides a stable power output to ensure efficient operation of the tail motor. This makes the toy plane's flight smoother and more reliable.

4. Electric toothbrush

In electric toothbrushes, the CST6116A not only provides a strong driving force, but also guarantees low noise and long life. Its efficient driving capacity and precise control performance make the use experience of electric toothbrushes greatly improved.

Ⅲ. Pin configuration and description

In order to better understand the functions and applications of the CST6116A, it is important to understand its pin configuration. The following is the main pin of the chip and its function description:

1. Power Input Pin (VDD)

It is used to connect the power supply voltage and usually works in the range of 2V to 6V. This pin provides the required power for the chip.

2. Ground pin (GND)

Common ground point for all electrical components to ensure circuit stability and safety.

3. PWM input pins (INA and INB)

It is used to receive PWM signals to control speed and direction. By adjusting the input signals of these two pins, the motor action can be flexibly controlled.

4. Output pins (OUTA and OUTB)

Two terminals connected to the motor to drive the operation of the motor. The voltage and current output from these two pins determine the speed and torque of the motor.

IV、Typical application circuit

In actual use, the typical application circuit of CST6116A is shown in the following figure. This circuit shows how the chip can be connected to power supplies, motors, and control signals to achieve full drive function.

   VDD ---+

          |         +-------- Positive electrode of machine

          |         |

          |         |         +---------+

          +---------+         |           |

          |                     |           |

          |     CST6116A       |           |

          |                     |           |

          |                     |           |

          +-----------+        +-----------+

          |   INA     |        |   OUTA    |

          +-----------+        +-----------+

          |   INB     |        |   OUTB    |

          +-----------+        +-----------+

          |   GND     |        |           |

          +-----------+        |           |


In this typical circuit, the VDD pin is connected to the power supply and the GND pin is grounded. The PWM signal is input through INA and INB pins to control the speed and direction of the motor. The OUTA and OUTB pins are connected directly to the motor to provide the required driving force. In this way, full control of the motor can be achieved.

V. Summary

ChipSourceTek-CST6116A is the ideal choice for many electronic device manufacturers due to its excellent performance, flexible application and high reliability. From toy cars to electric toothbrushes to all kinds of small appliances, this chip can provide stable and efficient drive solutions. In the future, with the progress of science and technology and the change of market demand, we have reason to believe that CST6116A will continue to play its advantages and provide strong support for more innovative products.
