两颗XS9110A功放双通道立体D类输出25W*2简单应用原理图
Date：May 8, 2022 Views：2302
XS9110A
是一款低 EMI，无需滤波器， AB/D类可选式音频功率放大器。14.4V工作电压时，最大驱动功率为25W（VDD=14.4V,4Ω BTL负载，THD<10%），音频范围内总谐波失真噪声小于1％（20Hz～20KHz)；
XS9110A
的应用电路简单，只需极少数外围器件；
XS9110A
输出不需要外接耦合电容或上举电容和缓冲网络；
XS9110A
采用ESOP8封装，特别适合用于小音量、小体重的便携系统中；
XS9110A
可以通过控制进入关断模式，从而减少功耗；
XS9110A
内部具有过流、欠压、短路以及过热自动关断保护机制；
XS9110A
工作稳定，通过配置外围电阻可以调整放大器的电压增益，方便应用。
