FM5010F
FM5010F mobile small fan control IC with flashlight function Integrated power management IC with lithium battery charging management, three gear voltage outputs, and corresponding status LED indicators.
The DC-DC boost of FM5010F can achieve an accuracy of ± 3%. FM5010F can support two button control and flashlight function. The output voltages of the FM5010F discharge driven small fan are 4.7V, 5.5V, and 6.5V, respectively.
FM5010F currently offers eSOP8L packaging form.
The DC-DC boost of FM5010F can achieve an accuracy of ± 3%. FM5010F can support two button control and flashlight function. The output voltages of the FM5010F discharge driven small fan are 4.7V, 5.5V, and 6.5V, respectively.
FM5010F currently offers eSOP8L packaging form.
FM5010F特性：
同步整流升压，升压部分无需 MOS 或二极管
外围电路简单，仅需三颗陶瓷电容。
低待机电流，小于 60uA
充电浮充电压精度±1%，充饱电压可选择 4.2V 和 4.35V
支持单按键和双按键模式，同时支持手电功能
OUT 输出有过流，短路保护
四灯和双灯状态显示方式
FM5010F提供eSOP8L封装
FM5010F应用:
锂电池供电小风扇
FM5010F典型应用电路:
FM5010F引脚示意图及说明：
FM5010F状态转换图：
FM5010F灯口接法：
FM5010F封装信息：
FM5010F应用:
锂电池供电小风扇
FM5010F典型应用电路:
FM5010F引脚示意图及说明：
FM5010F状态转换图：
FM5010F灯口接法：
FM5010F封装信息：
