CST6115

CST6115 is a brushed DC motor drive that can operate from 2.5V to 12V, providing an average drive current of 2.1A and a peak current of up to 4.0A. A simple PWM interface can achieve connection and control with the controller. When the system does not require a drive motor, the CST6115 can enter a low-power sleep mode. CST6115 is in SOP8 package.

CST6115 Description:

    CST6115 is a brushed DC motor driver, suitable for small household appliances, toys, electronic locks, advanced robots, digital products, and other small power tools and electromechanical equipment. Two logic inputs control the H-bridge driver, which consists of four N-channel metal-oxide-semiconductor field-effect transistors (MOSFETs) and is capable of bidirectional control of the motor at a peak current of up to 4.0A. By using the current attenuation mode, the motor speed can be controlled by pulse width modulation (PWM) of the input. If these two inputs are set to a low level and maintained for a period of time, the motor driver will enter a low-power sleep mode. CST6115 can provide internal shut-off functions for UVLO and overheat protection.
    The CST6115 integrates the four functions of forward rotation, reverse rotation, stop and braking of brushed motors. It can also drive one winding of a stepper motor and alternately drive with another CST6115 to achieve the stepper function.
    This device integrates various protection functions and can achieve internal shutdown in the event of a fault, providing overcurrent protection, undervoltage locking and overheat protection. In addition, a low-power sleep mode is also provided.
    CST6115 is available in a SOP8 package with a heat sink.
    CST6115 is a brushed DC motor drive that can operate from 2.5V to 12V, providing an average drive current of 2.1A and a peak current of up to 4.0A. A simple PWM interface can achieve connection and control with the controller. When the system does not require a drive motor, the CST6115 can enter a low-power sleep mode.
    CST6115 can provide internal s

CST6115 Features:

Single channel H-bridge motor driver with current control

Drive a DC motor, a stepper motor winding, or other load
Working voltage range: 2.5V-12V
Low on resistance: high side+low side (HS+LS=320mΩ)
Average current driving capability of 2.1A
Peak current driving capability of 4.0A

Pulse Width Modulation (PWM) Control Interface
Integrated protection features
  -VM undervoltage lockout (UVLO)
  -Thermal shutdown (TSD)
automatic crash recovery
Integrated current regulation function
Low power sleep mode

Provide SOP8 package with heat sink.


CST6115 Applications:

Small electronic lock
Toy
Robot
Digital products, etc


CST6115 Ordering Information:
Part No.
Package
Mark*
Tape/Reel
CST6115
SOP8
CST-LOGO: CST6115
TXX.XX
4000/Reel





CST6115 Application Circuit:


CST6115 Pin diagram and pin description:


CST6115 Functional Block Diagram:
