SA8301
The SA8301 provides an integrated motor drive solution for consumer products, toys and other low-voltage or battery-operated motion control applications. This device can drive a DC brushless motor, composed of power PMOS and NMOS, integrated motor forward/reverse/stop/brake four functions.
The SA8301 supports a maximum operating voltage of 7.0V, continuous current of 1.8A, and peak current of 2.5A. At the same time, it integrates protection functions such as over-temperature protection and under-voltage locking.
The SA8301 supports a maximum operating voltage of 7.0V, continuous current of 1.8A, and peak current of 2.5A. At the same time, it integrates protection functions such as over-temperature protection and under-voltage locking.
SA8301 Description:
The SA8301 provides an integrated motor drive solution for consumer products, toys and other low-voltage or battery-operated motion control applications. This device can drive a DC brushless motor, composed of power PMOS and NMOS, integrated motor forward/reverse/stop/brake four functions.
The SA8301 supports a maximum operating voltage of 7.0V, continuous current of 1.8A, and peak current of 2.5A. At the same time, it integrates protection functions such as over-temperature protection and under-voltage locking.
The SA8301 has a PWM (INA/INB) input interface that supports compatibility with industry standard devices.
SA8301 Feature:
Operating voltage range 2.0-7.0V
Continuous current 1.8A, peak 2.5A
Low on-resistance :450mΩ (HS+LS)
Low standby current (typ.0.1uA)
Low static operating current (typ.60uA)
Integrated overtemperature protection
Integrated undervoltage protection
SOP8 package
Continuous current 1.8A, peak 2.5A
Low on-resistance :450mΩ (HS+LS)
Low standby current (typ.0.1uA)
Low static operating current (typ.60uA)
Integrated overtemperature protection
Integrated undervoltage protection
SOP8 package
SA8301 Applications:
Small household appliances
plaything
Phone stand
plaything
Phone stand
SA8301 package and simple application circuit:
SA8301 Ordering Information:
Model number | Package | quantity | Operating temperature |
SA8301 | SOP8 | 4000 | -20~85℃ |
