The ME3118 is a simple and efficient synchronous rectifier step-down regulator with a maximum output current of 5A. The ME3118 has an input voltage range from 4.5V to 18V and can provide output current up to 5A and output voltage down to 0.8V. The product comes in an ESOP8 package with a heat sink and operates at -40 °C to +85 °C.

Continuous Output Current 5A (ESOP8), 4.2A (DFN)
4.5V to 18V operating voltage range
Synchronous buck: 43mΩ built-in high side switch and 40mΩ built-in low side switch (VIN=10V)
Up to 95% efficiency
External soft boot function
The output voltage is adjustable, minimum 0.8V
500 KHz PWM operating mode
Weekly term stream protection
Short circuit protection

DC/DC power supply
LCD TV
laptop
DVD and Blu-ray players
Fiber optic modulator

8-pin ESOP8

8-pin DFN3*3-8L
