The CST4056H is a highly integrated, cost-effective single lithium-ion battery charging chip that uses constant current/constant voltage linear control and requires fewer external components, making the CST4056H ideal for portable applications. At the same time, it can also be suitable for USB power supply and adapter power supply.
    The CST4056H uses an internal PMOSFET architecture with an anti-reverse charging path that eliminates the need for external detection resistors and isolation diodes. The thermal feedback automatically adjusts the charging current to limit the chip temperature under high-power operation or high ambient temperature conditions. The full voltage is fixed at 4.2V. The charging current can be set with an external resistor through the PROG pin, up to 1A.
When the input voltage (AC adapter or USB power supply) is removed, the CST4056H automatically enters a low current state, and the battery leakage current is below 3uA.
    Additional features of the CST4056H include a charge current monitor, input overvoltage protection, undervoltage latching, automatic recharging, and two status pins to indicate the end of charge and input voltage access.

Up to 30V input voltage and 6.9V overvoltage protection
High precision full detection voltage threshold: 4.2V accuracy ±42mV
Standby current <3uA
It has BAT-VDD anti-backfilling function
Support 0V battery charging
Linear charging mode, charging current up to 1A
Trickle/constant current/constant voltage three-stage charging
The charging current is externally adjustable
Charging current intelligent thermal regulation
Battery temperature detection protection
Automatic recharge
Charge status indication
Comply with IEC62368 latest standard
DFN8_2×2, ESOP8 package

Mobile phone, Bluetooth speaker
Portable media player
Bluetooth headset, wearable device
