D2822ML
The D2822ML is used as an audio power amplifier for portable recorders and radios.
Adopt DIP8,SOP8 package form.
Adopt DIP8,SOP8 package form.
D2822ML Description：
The D2822ML is used as an audio power amplifier for portable recorders and radios.
Adopt DIP8,SOP8 package form.
Adopt DIP8,SOP8 package form.
D2822ML Features:
The power supply voltage can still work normally when it is reduced to 1.8V
The crossover distortion is small
Low static current
Can be used for bridge or stereo power amplifier applications
Few peripheral components
High channel separation
No impact noise on startup and shutdown
Soft limiting
The crossover distortion is small
Low static current
Can be used for bridge or stereo power amplifier applications
Few peripheral components
High channel separation
No impact noise on startup and shutdown
Soft limiting
D2822ML Packaging Information:
Model number | Encapsulation form | Printing mode | Packing method |
D2822ML | DIP8 | CHMC D2822ML SXXXX | 50 PCS/tube |
D2822ML | SOP8 | CHMC D2822ML SXXXX | 100 PCS/tube 4000 PCS/disc |
D2822ML functional block diagram:
D2822ML pin arrangement diagram:
D2822ML test schematic diagram:
D2822ML application diagram:
