FM8002A
The FM8002A is an audio power amplifier for portable electronics. At 5V voltage, the maximum drive power is 1.5W (8Ω load) and 2.0W (4Ω load). The FM8002A's application circuit is simple and requires very few peripheral devices.
The FM8002A output does not require external coupling capacitors or up-lift capacitors and is packaged in SOP8, making it ideal for low-voltage, low-power audio applications. The FM8002A can be controlled into sleep mode to reduce power consumption.
The FM8002A output does not require external coupling capacitors or up-lift capacitors and is packaged in SOP8, making it ideal for low-voltage, low-power audio applications. The FM8002A can be controlled into sleep mode to reduce power consumption.
FM8002A Description:
No output coupling capacitors or external buffer circuits are required
Stable gain output
External gain setting
Package format: SOP-8
Stable gain output
External gain setting
Package format: SOP-8
Can be applied to portable devices
Desktop computer
Low voltage operating audio equipment
Desktop computer
Low voltage operating audio equipment
